| Type | Datasheet | Circuit | Marking | IF | IFSM | VRRM | VF | IR | Trr | Package | |
| Max | Typ | ||||||||||
| A | A | V | V | V | μA | nS | |||||
| 重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | |||||||||
| YFWD304065AC |
|
|
YFW D304065AC | 12 | 32 | 650 | 1.7 | 1.37 | 0.5 | / | TO-220AC |
| YFWD304065CS |
|
|
YFW D304065CS | 12 | 32 | 650 | 1.7 | 1.37 | 0.5 | / | TO-252 |
| YFWD304065FAC |
|
|
YFW D304065FAC | 12 | 32 | 650 | 1.7 | 1.37 | 0.5 | / | TO-252 |
| YFWD320120W |
|
|
YFW D320120W | 56 | 150 | 1200 | 1.7 | 1.37 | 4 | / | TO-247-2L |
| YFWD310120CS |
|
|
YFW D310120CS | 37 | 52 | 1200 | 1.8 | 1.4 | 2.4 | / | TO-252 |
| YFWD310120FAC |
|
|
YFW D310120FAC | 37 | 52 | 1200 | 1.8 | 1.4 | 2.4 | / | TO-220FAC |
| YFWD310120W |
|
|
YFW D310120W | 37 | 52 | 1200 | 1.8 | 1.4 | 2.4 | / | TO-247-2L |
| YFWD304065NT |
|
|
YFW D304065NT | 4 | 20 | 650 | 1.7 | 1.5 | 2 | / | PDFN5*6-8L |
| YFWD315065FAC |
|
|
YFW D315065FAC | 42 | 93 | 650 | 1.6 | 1.34 | 1 | / | TO-220FAC |
| YFWD302120CS |
|
|
YFW D302120CS | 9 | 30 | 1200 | 1.5 | 1.36 | 0.2 | / | TO-252 |
| YFWD330065FAC |
|
|
YFW D330065FAC | 70 | 170 | 650 | 1.7 | 1.34 | 3 | / | TO-220FAC |
| YFWD320065FAC |
|
|
YFW D320065FAC | 51 | 130 | 650 | 1.65 | 1.34 | 1.5 | / | TO-220FAC |
| YFWD330065W |
|
|
YFW D330065W | 70 | 170 | 650 | 1.7 | 1.34 | 3 | / | TO-247-2L |
| YFWD330065AC |
|
|
YFW D330065AC | 70 | 170 | 650 | 1.7 | 1.34 | 3 | / | TO-220FAC |
| YFWD320065AC |
|
|
YFW D320065AC | 51 | 130 | 650 | 1.65 | 1.34 | 1.5 | / | TO-220FAC |
| YFWD320065W |
|
|
YFW D320065W | 51 | 130 | 650 | 1.65 | 1.34 | 1.5 | / | TO-247-2L |
| YFWD320065FAC |
|
|
YFW D320065FAC | 51 | 130 | 650 | 1.65 | 1.34 | 1.5 | / | TO-220FAC |
| YFWD340120W |
|
|
YFW D340120W | 85 | 230 | 1200 | 1.8 | 1.41 | 8 | / | TO-247-2L |
| YFWD310065CS |
|
|
YFW D310065CS | 10 | 75 | 650 | / | 1.66 | 1 | 10 | TO-252 |
| YFWD306065FAC |
|
|
YFW D306065FAC | 20 | 63 | 650 | 1.5 | 1.7 | 1 | / | TO-220FAC |
| YFWD320060PT |
|
|
YFW D320060PT | 29.5 | 90 | 600 | 1.8 | 1.58 | 50 | / | TO-247 |
| YFWD310065FCT |
|
|
YFW D310065FCT | 33 | 90 | 650 | 1.6 | 1.45 | 65 | / | TO-220F |
| YFWD305120CS |
|
|
YFW D305120CS | 9.5 | 46 | 1200 | 3 | 1.9 | 150 | / | TO-252 |
| YFWD306065AC |
|
|
YFW D306065AC | 11 | 48 | 650 | 1.65 | 1.37 | 25 | / | TO-220AC |
| YFWD308065AC |
|
|
YFW D308065AC | 14 | 51 | 650 | 1.7 | 1.38 | 30 | / | TO-220AC |
| YFWD308065FAC |
|
|
YFW D308065FAC | 23 | 58 | 650 | 1.7 | 1.38 | 30 | / | TO-220FAC |
| YFWD308065FCT |
|
|
YFW D308065FCT | 6 | 20 | 650 | 2.4 | 1.57 | 120 | / | TO-220F |
| YFWD310065AC |
|
|
YFW D310065AC | 10 | 75 | 650 | 1.66 | 1.36 | 1 | / | TO-220AC |
| YFWD310065CT |
|
|
YFW D310065CT | 15 | 65 | 650 | 1.8 | 1.61 | 220 | / | TO-220AB |
| YFWD310065DC |
|
|
YFW D310065DC | 15 | 65 | 650 | 1.8 | 1.61 | 220 | / | TO-263 |
| YFWD310065FAC |
|
|
YFW D310065FAC | 10 | 75 | 650 | / | 1.66 | 1 | / | TO-220FAC |
| YFWD310120AC |
|
|
YFW D310120AC | 16 | 26 | 1200 | 3 | 2 | 4000 | / | TO-220AC |
| YFWD313065CS |
|
|
YFW D313065CS | 16 | 82 | 650 | 2.4 | 2 | 300 | / | TO-252 |
| YFWD315065AC |
|
|
YFW D315065AC | 15 | 93 | 650 | 1.61 | 1.34 | 1 | / | TO-220AC |
| YFWD320065PT |
|
|
YFW D320065PT | 15 | 71 | 650 | 2.4 | 1.7 | 200 | / | TO-247 |
| YFWD320120PT |
|
|
YFW D320120PT | 16.5/33 | 59.5* | 1200 | 3 | 2.2 | 52 | / | TO-247 |
