| Type | Datasheet | Circuit | Marking | Polarity | PCM | IC | VCBO | VCEO | VEBO | hFE | VCE | fT | Package | |
| (W) | (A) | (V) | (V) | (V) | Min | Max | (V) | (MHz) | ||||||
| 重置全部 | / | / | / |
Reset
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | ||||||||||||
| BC640 |
|
|
YFW BC640 | PNP | 1 | -1 | -100 | -80 | -5 | 63 | 400 | 0.5 | 100 | TO-92 |
| 2SC5171AF |
|
|
YFW 2SC5171AF | NPN | 2 | 2 | 180 | 180 | 5 | 100 | 320 | 1 | 200 | TO-220F |
| 2SC2908 |
|
|
YFW 2SC2908 | NPN | 50 | 5 | 200 | 100 | 12 | 60 | 320 | 1 | 1 | TO-247 |
| S9012 |
|
|
YFW S9012 | PNP | 0.625 | -0.5 | -40 | -30 | -5 | 64 | 350 | 0.6 | 20 | TO-92 |
| YFW13001 |
|
|
YFW 13001 | NPN | 0.75 | 0.18 | 600 | 400 | 7 | 10 | 40 | 0.5 | 8 | TO-92 |
| 2SC2383AD-R |
|
|
YFW 2SC2383AD-R | NPN | 1.5 | 1 | 160 | 160 | 6 | 60 | 120 | 1.5 | 20 | TO-252 |
| 2SC2383AD-O |
|
|
YFW 2SC2383AD-O | NPN | 1.5 | 1 | 160 | 160 | 6 | 100 | 200 | 1.5 | 20 | TO-252 |
| 2SC2383AD-Y |
|
|
YFW 2SC2383AD-Y | NPN | 1.5 | 1 | 160 | 160 | 6 | 160 | 320 | 1.5 | 20 | TO-252 |
| KTA1049-O |
|
|
YFW KTA1049 | PNP | 2 | -5 | -100 | -100 | -7 | 70 | 140 | -0.2 | 30 | TO-220F |
| KTA1049-Y |
|
|
YFW KTA1049 | PNP | 2 | -5 | -100 | -100 | -7 | 120 | 240 | -0.2 | 30 | TO-220F |
| KTC3228L-R |
|
|
YFW KTC3228 | NPN | 1 | 1 | 160 | 160 | 6 | 60 | 120 | 1.5 | 20 | TO-92L |
| KTC3228L-O |
|
|
YFW KTC3228 | NPN | 1 | 1 | 160 | 160 | 6 | 100 | 200 | 1.5 | 20 | TO-92L |
| KTC3228L-Y |
|
|
YFW KTC3228 | NPN | 1 | 1 | 160 | 160 | 6 | 160 | 320 | 1.5 | 20 | TO-92L |
| 2SC3303 |
|
/ | YFW 2SC3303 | NPN | 1.25 | 5 | 100 | 80 | 7 | 70 | 240 | 0.7 | 120 | TO-252 |
| 2N2222A |
|
|
YFW 2N2222A | NPN | 0.625 | 0.6 | 75 | 40 | 6 | 100 | 300 | 0.5 | 300 | TO-92 |
| 2N3904 |
|
|
YFW 2N3904 | NPN | 0.625 | 0.2 | 60 | 40 | 6 | 100 | 300 | 0.3 | 300 | TO-92 |
| 2N5551 |
|
|
YFW 2N5551 B | NPN | 0.625 | 0.1 | 180 | 160 | 6 | 80 | 250 | 0.2 | 100 | TO-92 |
| 2N6517 |
|
|
YFW 2N6517 | NPN | 0.625 | 0.5 | 350 | 350 | 6 | 30 | 200 | 0.5 | 200 | TO-92 |
| 2SC945 |
|
|
YFW 2SC945 | NPN | 0.25 | 0.15 | 60 | 50 | 5 | 90 | 600 | 0.3 | 300 | TO-92 |
| 2SC1815 |
|
|
YFW 2SC1815 | NPN | 0.4 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.3 | 80 | TO-92 |
| 2SC2240 |
|
|
YFW 2SC2240 | NPN | 0.3 | 0.1 | 120 | 120 | 5 | 200 | 700 | 0.3 | 100 | TO-92 |
| 2SC2383 |
|
|
YFW 2SC2383 | NPN | 0.7 | 1 | 180 | 160 | 6 | 60 | 320 | 1.5 | 20 | TO-92 |
| 2SD1616A |
|
|
YFW 2SD1616A | NPN | 0.75 | 1 | 120 | 60 | 6 | 135 | 600 | 0.3 | 100 | TO-92 |
| A44 |
|
|
YFW A44 | NPN | 0.625 | 0.2 | 400 | 400 | 5 | 80 | 300 | 0.2 | 50 | TO-92 |
| BC237 |
|
|
YFW BC237 | NPN | 0.5 | 0.1 | 50 | 45 | 6 | 120 | 800 | 0.2 | 150 | TO-92 |
| BC238 |
|
|
YFW BC238 | NPN | 0.5 | 0.1 | 30 | 25 | 5 | 120 | 800 | 0.2 | 150 | TO-92 |
| BC327 | / | / | YFW BC327 | NPN | 0.625 | 0.8 | 50 | 45 | 6 | 100 | 630 | 0.7 | 100 | TO-92 |
| BC546 |
|
|
YFW BC546 | NPN | 0.5 | 0.1 | 80 | 65 | 6 | 110 | 800 | 0.25 | 200 | TO-92 |
| BC547 |
|
|
YFW BC547 | NPN | 0.5 | 0.1 | 50 | 45 | 6 | 110 | 800 | 0.25 | 200 | TO-92 |
| BC548 |
|
|
YFW BC548 | NPN | 0.5 | 0.1 | 30 | 30 | 5 | 110 | 800 | 0.25 | 200 | TO-92 |
| BC549 |
|
|
YFW BC549 | NPN | 0.5 | 0.1 | 30 | 30 | 5 | 110 | 800 | 0.25 | 200 | TO-92 |
| BC550 |
|
|
YFW BC550 | NPN | 0.5 | 0.1 | 50 | 45 | 5 | 110 | 800 | 0.25 | 200 | TO-92 |
| BC639-10 |
|
|
YFW BC639-10 | NPN | 1 | 1 | 100 | 80 | 5 | 40 | 160 | 0.5 | 100 | TO-92 |
| BC639-16 |
|
|
YFW BC639-16 | NPN | 1 | 1 | 100 | 80 | 5 | 100 | 250 | 0.5 | 100 | TO-92 |
| C945 |
|
|
YFW C945 | NPN | 0.4 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.3 | 200 | TO-92 |
| D882SG |
|
|
YFW D882S | NPN | 0.625 | 3 | 40 | 30 | 6 | 60 | 400 | 0.5 | 80 | TO-92 |
| MPSA42 |
|
|
YFW MPSA42 | NPN | 0.625 | 0.5 | 300 | 300 | 6 | 40 | 0 | 0.5 | 40 | TO-92 |
| S8050 |
|
|
YFW S8050 | NPN | 0.625 | 0.5 | 40 | 25 | 6 | 85 | 320 | 0.6 | 100 | TO-92 |
| S9014 |
|
|
YFW S9014 | NPN | 0.45 | 0.1 | 50 | 45 | 5 | 60 | 1000 | 0.3 | 250 | TO-92 |
| SS8050 |
|
|
YFW SS8050 | NPN | 1 | 1.5 | 40 | 25 | 6 | 85 | 320 | 0.6 | 100 | TO-92 |
| YFW13003B |
|
|
YFW 13003B | NPN | 0.9 | 0.5 | 700 | 400 | 9 | 10 | 40 | 0.5 | 8 | TO-92 |
| 2N3906 |
|
|
YFW 2N3906 | PNP | 0.625 | -0.2 | -40 | -40 | -5 | 100 | 300 | -0.4 | 250 | TO-92 |
| 2SA970 |
|
|
YFW 2SA970 | PNP | 0.3 | -0.1 | -120 | -120 | -5 | 150 | 700 | -0.3 | 100 | TO-92 |
| 2SA1015 |
|
|
YFW 2SA1015 | PNP | 0.4 | -0.15 | -50 | -50 | -5 | 70 | 400 | -0.3 | 80 | TO-92 |
| BC327 |
|
|
YFW BC327 | PNP | 0.625 | -0.8 | -50 | -45 | -5 | 100 | 630 | -0.7 | 260 | TO-92 |
| BC328 |
|
|
YFW BC328 | PNP | 0.625 | -0.8 | -30 | -25 | -5 | 100 | 630 | -0.7 | 260 | TO-92 |
| BC516 |
|
|
YFW BC516 | PNP | 0.625 | -1 | -40 | -30 | -10 | 20000 | 0 | 1 | 200 | TO-92 |
| BC556 |
|
|
YFW BC556 | PNP | 0.5 | -0.1 | -80 | -65 | -5 | 110 | 800 | -0.3 | 200 | TO-92 |
| BC557 |
|
|
YFW BC557 | PNP | 0.5 | -0.1 | -50 | -45 | -5 | 110 | 800 | -0.3 | 200 | TO-92 |
| BC558 |
|
|
YFW BC558 | PNP | 0.5 | -0.1 | -30 | -30 | -5 | 110 | 800 | -0.3 | 200 | TO-92 |
| BC559 |
|
|
YFW BC559 | PNP | 0.5 | -0.1 | -30 | -30 | -5 | 110 | 800 | -0.3 | 200 | TO-92 |
| BC560 |
|
|
YFW BC560 | PNP | 0.5 | -0.1 | -50 | -45 | -5 | 110 | 800 | -0.3 | 200 | TO-92 |
| KTA1273 |
|
|
YFW KTA1273 | PNP | 0.625 | -2 | -30 | -30 | -5 | 110 | 320 | -2 | 120 | TO-92 |
| MPSA92 |
|
|
YFW MPSA92 | PNP | 0.625 | -0.5 | -300 | -300 | -5 | 40 | 0 | -0.5 | 40 | TO-92 |
| 2SA1013L |
|
|
YFW 2SA1013 | PNP | 0.9 | -1 | -160 | -160 | -6 | 60 | 320 | -1.5 | 20 | TO-92L |
| 2SC2383L-R |
|
|
YFW 2SC2383 | NPN | 0.9 | 1 | 180 | 160 | 6 | 60 | 320 | 1.5 | 20 | TO-92L |
| 2SC2655L |
|
|
YFW 2SC2655 | NPN | 0.9 | 2 | 50 | 50 | 5 | 70 | 240 | 0.5 | 50 | TO-92L |
| 2SD882 |
|
|
YFW 2SD882 | NPN | 1 | 3 | 40 | 40 | 5 | 100 | 400 | 0.5 | 50 | TO-126 |
| 2SD1691 |
|
|
YFW 2SD1691 | NPN | 1.3 | 5 | 60 | 60 | 7 | 100 | 400 | 0.3 | 50 | TO-126 |
| BD135 |
|
|
YFW BD135 | NPN | 12.5 | 1.5 | 45 | 45 | 5 | 40 | 250 | 0.5 | 50 | TO-126 |
| BD137 |
|
|
YFW BD137 | NPN | 12.5 | 1.5 | 60 | 60 | 5 | 40 | 250 | 0.5 | 50 | TO-126 |
| BD139 |
|
|
YFW BD139 | NPN | 12.5 | 1.5 | 80 | 80 | 5 | 40 | 160 | 0.5 | 50 | TO-126 |
| BD233 |
|
|
YFW BD233 | NPN | 36 | 2 | 45 | 45 | 5 | 40 | 0 | 0.6 | 3 | TO-126 |
| BD235 |
|
|
YFW BD235 | NPN | 36 | 2 | 60 | 60 | 5 | 40 | 0 | 0.6 | 3 | TO-126 |
| BD237 |
|
|
YFW BD237 | NPN | 36 | 2 | 100 | 80 | 5 | 40 | 0 | 0.6 | 3 | TO-126 |
| BD433 |
|
|
YFW BD433 | NPN | 1.25 | 4 | 22 | 22 | 5 | 85 | 140 | 0.5 | 3 | TO-126 |
| BD435 |
|
|
YFW BD435 | NPN | 1.25 | 4 | 32 | 32 | 5 | 85 | 140 | 0.5 | 3 | TO-126 |
| BD437 |
|
|
YFW BD437 | NPN | 1.25 | 4 | 45 | 45 | 5 | 85 | 140 | 0.5 | 3 | TO-126 |
| BD441 |
|
|
YFW BD441 | NPN | 1 | 4 | 80 | 80 | 5 | 40 | 475 | 0.8 | 3 | TO-126 |
| YFW13003 |
|
|
YFW 13003 | NPN | 1.25 | 1.5 | 700 | 480 | 9 | 8 | 40 | 0.5 | 8 | TO-126 |
| 2SB772 |
|
|
YFW 2SB772 | PNP | 1 | -3 | -40 | -30 | -5 | 100 | 400 | -0.5 | 50 | TO-126 |
| BD136 |
|
|
YFW BD136 | PNP | 1.25 | -1.5 | -45 | -45 | -5 | 40 | 250 | -0.5 | 3 | TO-126 |
| BD138 |
|
|
YFW BD138 | PNP | 1.25 | -1.5 | -60 | -60 | -5 | 40 | 250 | -0.5 | 3 | TO-126 |
| BD140 |
|
|
YFW BD140 | PNP | 1.25 | -1.5 | -80 | -80 | -5 | 40 | 250 | -0.5 | 3 | TO-126 |
| BD238 |
|
|
YFW BD238 | PNP | 25 | -2 | -100 | -80 | -5 | 40 | 0 | -0.6 | 3 | TO-126 |
| BD434 |
|
|
YFW BD434 | PNP | 36 | -4 | -22 | -22 | -5 | 85 | 140 | -0.5 | 3 | TO-126 |
| BD436 |
|
|
YFW BD436 | PNP | 36 | -4 | -32 | -32 | -5 | 85 | 140 | -0.5 | 3 | TO-126 |
| BD438 |
|
|
YFW BD438 | PNP | 36 | -4 | -45 | -45 | -5 | 85 | 140 | -0.5 | 3 | TO-126 |
| BD440 |
|
|
YFW BD440 | PNP | 1 | -4 | -60 | -60 | -5 | 40 | 0 | -0.8 | 3 | TO-126 |
| KTA1381 |
|
|
YFW KTA1381 | PNP | 1.5 | -0.1 | -300 | -300 | -5 | 60 | 200 | -0.6 | 140 | TO-126 |
| MJE350G |
|
|
YFW MJE350G | PNP | 20 | -0.5 | -300 | -300 | -5 | 30 | 240 | -0.5 | 3 | TO-126 |
| 2SC4793 |
|
|
YFW 2SC4793 | NPN | 2 | 1 | 230 | 230 | 5 | 100 | 320 | 1.5 | 100 | TO-220F |
| 2SC4977 |
|
|
YFW 2SC4977 | NPN | 40 | 7 | 450 | 400 | 8 | 10 | 0 | 0.8 | 100 | TO-220F |
| 2SA1943 |
|
|
YFW 2SA1943 | PNP | 130 | -15 | -230 | -230 | -5 | 55 | 160 | -0.4 | 30 | TO-247 |
| 2SC4467 |
|
|
YFW 2SC4467 | NPN | 3.5 | 8 | 160 | 120 | 6 | 50 | 180 | 1.5 | 20 | TO-247 |
| 2SC5200 |
|
|
YFW 2SC5200 | NPN | 130 | 15 | 230 | 230 | 5 | 55 | 160 | 0.4 | 30 | TO-247 |
| TIP3055 |
|
|
YFW TIP3055 | NPN | 90 | 15 | 100 | 60 | 7 | 20 | 70 | 1 | 3 | TO-247 |
| 2SB772AD |
|
|
YFW 2SB772 | PNP | 10 | -2 | -40 | -30 | -5 | 60 | 400 | -0.5 | 50 | TO-252 |
| 2SC2983 |
|
|
YFW 2SC2983 | NPN | 1 | 1.5 | 160 | 160 | 5 | 70 | 240 | 1.5 | 100 | TO-252 |
| 2SD882AD |
|
|
YFW 2SD882 | NPN | 1.25 | 3 | 40 | 30 | 6 | 60 | 400 | 0.5 | 50 | TO-252 |
| 2SD1804 |
|
|
YFW 2SD1804 | NPN | 1 | 8 | 60 | 50 | 6 | 70 | 400 | 0.4 | 100 | TO-252 |
| 3DD13003 |
|
|
YFW 3DD13003 | NPN | 20 | 1.5 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-252 |
| MJE13002 |
|
|
YFW MJE13002 | NPN | 1.2 | 1 | 700 | 480 | 9 | 8 | 40 | 0.5 | 8 | TO-252 |
| YFW13005AD |
|
|
YFW 13005AD | NPN | 80 | 4 | 700 | 400 | 9 | 30 | 40 | 0.5 | 4 | TO-252 |
| 2SD880 |
|
|
YFW 2SD880 | NPN | 2 | 3 | 60 | 60 | 7 | 60 | 300 | 1 | 3 | TO-220AB |
| BD649 |
|
|
YFW BD649 | NPN | 2 | 8 | 100 | 100 | 5 | 750 | 0 | 2 | 3 | TO-220AB |
| YFW13003AT |
|
|
YFW 13003AT | NPN | 1.5 | 1.5 | 700 | 400 | 9 | 15 | 30 | 0.6 | 5 | TO-220AB |
| YFW13003AF |
|
|
YFW 13003AF | NPN | 1.5 | 1.5 | 700 | 400 | 9 | 15 | 30 | 0.6 | 5 | TO-220F |
| YFW13003AS |
|
|
YFW 13003AS | NPN | 1.5 | 1.5 | 700 | 400 | 9 | 15 | 30 | 0.6 | 5 | TO-263 |
| YFW13005AT |
|
|
YFW 13005AT | NPN | 1.25 | 4 | 800 | 450 | 9 | 15 | 35 | 1 | 4 | TO-220AB |
| YFW13005AF |
|
|
YFW 13005AF | NPN | 1.25 | 4 | 800 | 450 | 9 | 15 | 35 | 1 | 4 | TO-220F |
| YFW13005AS |
|
|
YFW 13005AS | NPN | 1.25 | 4 | 800 | 450 | 9 | 15 | 35 | 1 | 4 | TO-263 |
| YFW13007AT |
|
|
YFW 13007AT | NPN | 2 | 8 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-220AB |
| YFW13007AF |
|
|
YFW 13007AF | NPN | 2 | 8 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-220F |
| YFW13007AS |
|
|
YFW 13007AS | NPN | 2 | 8 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-263 |
| YFW13009AT |
|
|
YFW 13009AT | NPN | 3 | 12 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-220AB |
| YFW13009AF |
|
|
YFW 13009AF | NPN | 3 | 12 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-220F |
| YFW13009AS |
|
|
YFW 13009AS | NPN | 3 | 12 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-263 |
| YFW13009PT |
|
|
YFW 13009PT | NPN | 3 | 12 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-247 |
| YFW13009PTS |
|
|
YFW 13009PTS | NPN | 3 | 12 | 700 | 400 | 9 | 8 | 40 | 1 | 4 | TO-247S |
